Technical Paremeter for Four meters small compact electric forklift
| Model Parameter | CPD1030 | CPD1530 | CPD2030 |
| Load Capacity(Kg) | 1000 | 1500 | 2000 |
| Lift Height(m) | 3000 | 3000 | 3000 |
| Load Center (mm) | 500 | 500 | 500 |
| Fork Length (mm) | 1070 | 1070 | 1070 |
| Lowest height(mm) | 100 | 100 | 100 |
| Manipulation Way | Steering Wheel | Steering Wheel | Steering Wheel |
| Tyres | Solid Tyre | Solid Tyre | Solid Tyre |
| Dimension of Driving Wheel | 350*100 | 350*100 | 250*80 |
| Speed at Full Load km/h | 8 | 8 | 5 |
| Lifting Speed at full Load mm/sec | 80 | 80 | 80 |
| Speed Control Way | Stepless Speed Regulating | Stepless Speed Regulating | Stepless Speed Regulating |
| Door Frame Angle ° | 3~6 | 3~6 | 3~6 |
| Gradient at full Load ° | 10 | 8 | 8 |
| Battery V/Ah | 48/120 | 48/120 | 24/240 |
| Working Time(for reference) (h) | 4 | 3.5 | 3 |
| Driving Motor (kw) | 2.2 | 2.2 | 1.5 |
| Lifting Motor (kw) | 3 | 3 | 3 |
| The Min. Turning Inner Radius (mm) | 1750 | 1800 | 1800 |
| L X W X H Dimension (mm) | 3100*1050*2080 | 3100*1050*2080 | 3100*930*2080 |
| weight(kg) | 1600 | 1700 | 1800 |
| lifting Height at each weight (mm) | 1600/2000/2500/3000/3500 | ||
| Height of Door Frame (mm) | 2080/1600/1850/2080/2350 | ||
1. Color : yellow, orange, blue or according to your requirements.
2. Capacity: 1000kg/ 1500kg/ 2000kg/3000kg are available.
3. Lifting height can be customized as your request.
4. No polluting and energy-saving, can be operated for long hours after each charge.
5. Compact body structure for easy operatation.
6. Low cost for replacement parts and maintenance.
Packing for Four meters small compact electric forklift
Wrapped by carton and PVC film and Load on Steel Pallet.
Who Are We?
Jiangsu Zhongyan Forklift Manufacturing Co., Ltd. was established in 1997, covering an area of 21,800m2 and owing a registered capital of 40 million RMB. It is a high-tech environmentally friendly enterprise specialized in research, production and marketing, and a cooperative company with the logistic department of national army for handling equipment. It is located in China historical and cultural city----Taixing, the north of Yangtze River delta.
We attach importance to institutionalized and standardized construction, and established such regulations as pre-delivery inspection, product recall and product exchange/compensation for defect products. We can design and customize the needed products according to the practical usage situation and customers' requirements. For more than 2 decades, Zhongyan gained high reputation among customers from all over the world with its high quality and sound after-sale services.
Warranty
Warranty time: 1 Year.
