Technical Data Sheet
| 1 | Model | CTDN1016 | CTDN1020 | CTDN1025 | CTDN1030 | CTDN1516 | CTDN1520 | CTDN1525 | CTDN1530 | CTDN2016 | CTDN2020 | |||
| 2 | Capacity (kg) | 1000 | 1500 | 2000 | ||||||||||
| 3 | Self weight (kg) | 350 | 370 | 390 | 410 | 370 | 390 | 410 | 430 | 380 | 400 | |||
| Size | 4 | Max lifting height (mm) | 1600 | 2000 | 2500 | 3000 | 1600 | 2000 | 2500 | 3000 | 1600 | 2000 | ||
| 5 | Min lifting height (mm) | 90 | 90 | 90 | ||||||||||
| 6 | Fork length (mm) | 900/1000/1150 | 900/1000/1150 | 900/1000/1150 | ||||||||||
| 7 | Fork width ( mm) | Fixed fork | 550 | 550 | 550 | |||||||||
| Adjust table | 360-690 | 360-690 | 360-690 | |||||||||||
| 8 | Overall length (mm) | 1570/1670/1820 | 1570/1670/1820 | 1570/1670/1820 | ||||||||||
| 9 | Overall width (mm) | 950 | 950 | 950 | ||||||||||
| 10 | Overall height (mm) | Closed | 2080 | 1580 | 1850 | 2080 | 2080 | 1580 | 1850 | 2080 | 2080 | 1580 | ||
| Opened | 2080 | 2580 | 3100 | 3580 | 2080 | 2580 | 3100 | 3580 | 2080 | 2580 | ||||
| 11 | Loading center (mm) | 400 | 400 | 400 | ||||||||||
| 12 | Minimum ground clearance (mm) | 31 | 31 | 31 | ||||||||||
| 13 | Turning radius (mm) | 1280/1380/1530 | 1280/1380/1530 | 1280/1380/1530 | ||||||||||
| 14 | Front wheel (mm) | Φ180*50 | Φ180*50 | Φ180*50 | ||||||||||
| 15 | Rear wheel (mm) | Φ80*93 | Φ80*93 | Φ80*93 | ||||||||||
| Other | 16 | Battery (V/Ah) | 12/120 | 12/120 | 12/120 | |||||||||
| 17 | Battery(kw) | 1.6 | 1.6 | 1.6 | ||||||||||
