Ltmg forklift brands 2 ton electric forklift price
The specification of 2 Ton Electric Forklift
Product Features
1.Equipped with original imported American Curtis electric control system; High voltage and large capacity battery can supply the forklift with strong power; DC or AC motors are optional according to customers' requirements.
2.Designed to work in the rain, electric forklift can be used in various kinds of wet and dry environments.
3.Ergonomics Adjustable seat:Designed according to the ergonomic principles, make the operation much comfortable and also relieves the fatigue caused by long continuous operation.
4.Bigger and non-slip step make operating convenient and safe.
5.The standard LED lamps and warning lights make it safer ,more energy efficient and create better working condition
After sales service
Customer show
The specification of 2 Ton Electric Forklift
| Manufacturer | LTMG | |||
| Model | FB20 | |||
| Load capacity | kg | 2000 | ||
| Load center | mm | 500 | ||
| Power unit | Battery | |||
| Operator type | Driver/seat | |||
| Tire type | pneumatic | |||
| Wheel(x=driving) | Front/rear | 2X/2 | ||
| Max. lifting height | mm | 3000 | ||
| Free lift | mm | 160 | ||
| Fork size | L*W*T | mm | 1070*122*40 | |
| Tilt range | Mast forward/backward | deg | 6/12 | |
| Overall length(without fork) | mm | 2245 | ||
| Total width | mm | 1150 | ||
| Mast height (fork lowering) | mm | 1995 | ||
| Overall height fork raised | With backrest | mm | 4030 | |
| Height to head guard | mm | 2145 | ||
| Turning radius(outside) | mm | 1980 | ||
| Front overhang ( face of fork to front axle) | mm | 445 | ||
| Min. right angle stacking aisle | not add load length&clearance | mm | 2425 | |
| Speed | Max Travellingfull load | km/h | 13.5 | |
| Max Travellingno load | km/h | 15 | ||
| Liftingfull load | mm/s | 240 | ||
| Liftingno load | mm/s | 450 | ||
| Gradeability | full load | % | 12.5 | |
| Truck weight(with standard battery) | kg | 3440 | ||
| Weight distribution | Fullloadfront/rear | kg | 4565/875 | |
| Noloadfront/rear | kg | 1445/1995 | ||
| Tires | Number | front/rear | 2/2 | |
| Model | front axle | 21*8-9-16PR | ||
| rear axle | 18*7-8-14PR | |||
| Wheelbase | mm | 1400 | ||
| Tread | Front/rear | mm | 955/950 | |
| Ground clearance | At lowest point(mast) | mm | 110 | |
| Frame | mm | 115 | ||
| Brake | Servicebrake | Hydraulic-foot pedal | ||
| Parking brake | Mechanical-hand lever | |||
| Battery | Voltage/capacity | V/AH/5hr | 48V-450 | |
| Weight with box(standard) | kg | 825 | ||
| Electric motor | AC Driving motor | kw | 11 | |
| DC Hydraulic driving motor | kw | 8.6 | ||
| AC Hydraulic driving motor (as option) | kw | 13 | ||
| Control type | Driving AC , lifting DC Driving AC , lifting AC (as option ) | |||
| Operating pressure | kg/cm² | 175 | ||
Product Features
1.Equipped with original imported American Curtis electric control system; High voltage and large capacity battery can supply the forklift with strong power; DC or AC motors are optional according to customers' requirements.
2.Designed to work in the rain, electric forklift can be used in various kinds of wet and dry environments.
3.Ergonomics Adjustable seat:Designed according to the ergonomic principles, make the operation much comfortable and also relieves the fatigue caused by long continuous operation.
4.Bigger and non-slip step make operating convenient and safe.
5.The standard LED lamps and warning lights make it safer ,more energy efficient and create better working condition
Packaging&Shipping
After sales service
LTMG always treat after-sale service as important the same as product quality.
LTMG grants our clients a twelve-month-period or 2000 working hours warranty for any machine purchased from us.
LTMG can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine. With our technical advises, your machine service life can be significantly prolonged and sustained with high capacity.
Customer show
